Round conductor, copper sheathed
Type RD 10-ST CU 100
|Item no. 5450085
|EAN 4012197007836
Item no. / Type
5450085 / RD 10-ST CU 100
Material
Steel
Smallest selling unit: 25 m
25m
m
Description
• According to IEC/ EN 62561-2 (VDE 0185-561-2)
• Meets the requirements of VDE 0185-305 (IEC 62305)
• Copper layer thickness: Min. 250 µm
• Meets the requirements of VDE 0185-305 (IEC 62305)
• Copper layer thickness: Min. 250 µm
Technical data
Dimensions
| Length | 10000 mm |
|---|
Technical data
| Diameter | 8 mm |
|---|---|
| High voltage-resistant, insulated version | no |
| Number of individual wires | 1 |
| Cross-section | 50 mm² |
| Dimension | 10mm |
| Surface | Copper-plated |
| Material | Steel |
| Length tolerance ± | 5 % |
Downloads
0 selected
Data sheet (1)
Catalogues & Flyers (1)
Product images (2)
Tender specifications (2)
Variants
Type
Diameter
Cross-section
Material
Item no.
RD 10-ST CU 100
8
50
Steel
5450085
RD 10-ST CU 100
Item no.
5450085
Diameter
8
Cross-section
50
Material
Steel
