Washer
Type WS M12 D24 G
|Item no. 3402126
|EAN 4012195300199
Item no. / Type
3402126 / WS M12 D24 G
Thread
M12
Smallest selling unit: 100 piece
100piece
piece
Description
Washer according to DIN 125, shape A, for universal use.
Technical data
Technical data
| Material thickness | 2,5 mm |
|---|---|
| Thread | M12 |
| Hardened | no |
| Inner diameter | 13 mm |
| With toothing | no |
| External diameter | 24 mm |
| Faceted | no |
| Dimension | M12 |
| Surface | Electrogalvanized |
| Material | Steel |
| Hole shape | Round |
| CO2 Footprint (GWP) Cradle-to-Gate | 0,0156 kg CO2e / 1 Piece |
Dimensions
| Dimension d | 13 mm |
|---|---|
| Dimension d min. | 24 mm |
| Dimension h | 2,5 mm |
Downloads
0 selected
Data sheet (1)
Catalogues & Flyers (4)
Declarations (2)
Product images (2)
3D data downloads (2)
Tender specifications (2)
Variants
Type
Dimension d
Thread
Dimension d min.
Dimension h
Item no.
WS M12 D24 G
13
M12
24
2,5
3402126
WS M12 D24 G
Item no.
3402126
Dimension d
13
Thread
M12
Dimension d min.
24
Dimension h
2,5
