Connection clip for earthing rod, universal
Type 2760 17 SS316
|Item no. 5450532
|EAN 4012197011871
Item no. / Type
Smallest selling unit: 1 piece
1piece
piece
Description
• Meets the requirements of VDE 0185-305-3 (IEC/ EN 62305-3)
• Fit: Max. FL 30 x FL 30
• Without adapter plate
• Mounted with 4 hexagonal bolts M8 x 25 and 4 hexagonal nuts M8
• Fit: Max. FL 30 x FL 30
• Without adapter plate
• Mounted with 4 hexagonal bolts M8 x 25 and 4 hexagonal nuts M8
Technical data
Technical data
| Suitable for round conductor diameters, min. | 8 mm |
|---|---|
| Suitable for round conductor diameters, max. | 10 mm |
| Type | Connection clip |
| Fit | Rd 8-10/FL40 mm |
| Dimension | 17.2mm |
| Material | Stainless steel |
| Clamping range, min. | 8 mm |
| Clamping range, max. | 10 mm |
Downloads
0 selected
Data sheet (1)
Catalogues & Flyers (2)
Instructions and Aid (1)
Product images (2)
Tender specifications (2)
Variants
Type
Item no.
2760 14 SS316
5450530
2760 17 SS316
5450532
2760 20 SS316
5450534
2760 25 SS316
5450536
2760 14 SS316
Item no.
5450530
2760 17 SS316
Item no.
5450532
2760 20 SS316
Item no.
5450534
2760 25 SS316
Item no.
5450536
