Barrier strip 100 FS
Type GKSTSG 100 FS
|Item no. 6480113
|EAN 4012195486671
Item no. / Type
6480113 / GKSTSG 100 FS
Smallest selling unit: 3 m
3m
m
Description
Barrier strip to separate cables, for installation in cable trays with fastening accessories
Including appropriate fastening material.
Technical data
Dimensions
| Length | 3000 mm |
|---|---|
| Height | 100 mm |
| Dimension L | 3000 mm |
| Dimension H | 100 mm |
Technical data
| Maintain electrical functions | no |
|---|---|
| Rustproof steel, pickled | no |
| Plate thickness | 0,6 mm |
| Suitable for mesh cable tray | yes |
| Suitable for cable ladder | yes |
| Suitable for cable tray | yes |
| Fastening perforation (ETIM) | no |
| Fastening type | Screw-on |
| Dimension | 100x3000 |
| Surface | Strip galvanized |
| Material | Steel |
| Colour | zinc |
